Dt-swiss DT Swiss XMC 1200 SPLINE 30 29

Please, ask for availability before ordering.

Thank you.

The XMC 1200 SPLINE® are for anyone who enjoys high-speed climbing and descending. Fitted with tubeless tires, the full carbon hookless rims massively reduces the chance of punctures. They are superlight and the 30mm internal width works to perfection with wide all mountain rubber. The SPLINE® hubs are the lightest wheel hubs ever built by DT Swiss, together with the bladed top end spokes and a perfect DT Swiss wheel build it complements the carbon rims for the ultimate trailbike wheelset.

Equipped with 30mm high and 36mm wide, tubeless ready carbon rims with an internal witdh of 30mm, DT aero comp® spokes, centerlock disc mounts incl. IS 6-bolt adapter and 240s based SPLINE® hubs with 36T ratchet system. Version for 15x110mm and 12x148mm boost thru axles.

The rear wheel comes with a Shimano 9/10/11-speed freehub body, a second freehub body for SRAM XD 11/12-speed is also included.

SPLINE® Technology

With straight pull spokes and the use of specific lacing, superlight hubs as well as high end rims featuring key DT Swiss technology, SPLINE® wheels make for a perfect training and racing partner.

Straightpull Technology

The term Straightpull refers to spokes with no bend at the head. This design allows for an ideal strength to weight ratio when compared to conventional spokes. Due to their more precise alignment and direct trajectory, straight-pull spoke technology creates a stiffer, more responsive wheel.

DT Pro Lock® Technology

A patented liquid injected into the nipple thread allows for extremely durable wheel builds.

Ratchet System®

This patented freewheel system uses precision ratchets, featuring extremely high load capacity and reliability. The no tool concept allows for an easy execution of routine maintenance.

Maximum system weight: 120kg!

Year: 2018

Manufacturer item code: FW: WXMC120BEIXCA05041

RW: WXMC120TEDRCA05045

E.T.R.T.O: 30-622

Material: rims: carbon

spokes: stainless steel

nipples: aluminum

Weight: approx. 1547 gram (per set)

approx. 712 grams (front)

approx. 835 grams (rear)

(manufacturer information)

Spokes: DT aero comp®

Spokes number: 28 (3x crossed)

Nipples: DT Pro Lock®

Rim: carbon | UD-finish | tubeless ready

Rim width: 36mm / 30mm

Rim height: 30mm

Hub: DT Swiss SPLINE® | 240s based

Purpose: cross country, trail, all mountain

Fitting for shifting: Shimano 9-/10-/11-speed

SRAM XD 11-/12-speed

Disc brake standard: centerlock / IS 6-bolt

Fitting type of tire: clincher

Hub axle system: FW: 15x110mm boost

RW: 12x148mm boost

Included in delivery: tubeless ready tape, tubeless valve, IS 6-bolt adapter, wheel bag, SRAM XD freehub body, Shimano freehub body

Weight limit: 120kg
