Carbon-Ti X-Carboring SRAM AXS 12 Speed 4 Arms

Before ordering, ask for availability.

Thank you.

X-CarboRing X-AXS is the latest evolution of superlight racing bike chainrings with a composite structure in aluminium alloy and carbon fibre offered by Carbon-Ti. The structural carbon fibre body features CNC machining and shaped Grade 5 Titanium pins to allow lightning-fast and precise shifting with both mechanical and electronic derailleurs. Each single tooth in AL7075-T6 aluminium alloy is individually CNC machined with a specific shape to optimise operation in all conditions.

Sram AXS 12s groupsets require specific “X-AXS” sprockets, which are now also available for SRAM Force 12s and Rival 12s cranks and power meters with 107 mm bolt spacing.

The outer chainrings are now machined from thicker carbon fibre plates to achieve significantly greater rigidity and allow even more elaborate CNC machining.

Features

AL7075-T6 aluminium alloy chainring, structural carbon fibre with 3K polished finish and Grade 5 titanium pin

Internal chainring with 107mm BCD 4-arm, compatible with SRAM Force and Rival AXS 12s cranks and powermeters

Compatible with SRAM AXS 12 speed road groupsets

Allows significant weight savings compared to original SRAM sprockets

The use of the specific X-Fix BCD107 2X kit is recommended for assembly

Actual weight: 30g (33t), 33g (35t), 37g (42t), 85g (46t), 96g (48t), 104g (50t)

Notes

X-CarboRing 50 x 107 X-AXS to be installed with X-CarboRing 37 x 107 X-AXS

X-CarboRing 48 x 107 X-AXS to be installed with X-CarboRing 35 x 107 X-AXS

X-CarboRing 46 x 107 X-AXS to be installed with X-CarboRing 33 x 107 X-AXS
